Specs
| Model | Deck Width | Engine | Horsepower | MSRP |
|---|---|---|---|---|
SCZII-61V-36BV  | 61″ | Vanguard™ BIG BLOCK™ Non-Suspension Seat | 36 | $13,999 |
| SCZII-61V-37BV-EFI | 61″ | Vanguard™ BIG BLOCK™ EFI – electronic fuel injection | 37 | $16,899 |
SCZII-61V-38CV-EFI  | 61″ | Kohler® Command PRO® EFI – electronic fuel injection | 38 | $16,699 |
| SCZII-61V-38FX-EFI | 61″ | Kawasaki® FX Series EFI – electronic fuel injection | 38 | $16,999 |
| SCZII-61V-38FX-EFI-NFT | 61″ | Kawasaki® FX Series EFI – electronic fuel injection | 38 | $18,499 |
| SCVII-61V-40BV-EFI | 61″ | Vanguard™ BIG BLOCK™ EFI – electronic fuel injection | 40 | $16,999 |
| SCZII-72V-37BV-EFI | 72″ | Vanguard™ BIG BLOCK™ EFI – electronic fuel injection | 37 | $17,499 |
| SCZII-72V-38CV-EFI | 72″ | Kohler® Command PRO® EFI – electronic fuel injection | 38 | $17,749 |
| SCZII-72V-38FX-EFI | 72″ | Kawasaki® FX Series EFI – electronic fuel injection | 38 | $17,999 |
| SCZII-72V-40BV-EFI | 72″ | Vanguard™ BIG BLOCK™ EFI – electronic fuel injection | 40 | $17,999 |
| Rear Discharge | ||||
| SCZII-61RD-38FX-EFI | 61″  | Kawasaki® FX Series EFI – electronic fuel injection | 38 | $17,249 |
| SCZII-61RD-38CV-EFI | 61″ | Kohler® Command PRO® EFI – electronic fuel injection | 38 | $17,249 |
| SCZII-72RD-40BV-EFI | 72″ | Vanguard™ BIG BLOCK™ EFI – electronic fuel injection | 40 | $18,299 |
| SCZII-72RD-38FX-EFI | 72″ | Kawasaki® FX Series EFI – electronic fuel injection | 38 | $18,299 |
| Specifications and prices subject to change without notice. Actual ground speeds may vary. Accessories subject to availability. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. Contact your local Scag dealer for specific availability information. | ||||
| Product Dimensions | 61″ Cheetah | 72″ Cheetah |
|---|---|---|
| Length | 87″-91.25″ | 91″-97.5″ |
| Width (chute down) | 73.5″ | 83″ |
| Width (chute in transport position) | 62.75″ | 73″ |
| Height (ROPS folded) | 49.5″ | 49.5″ |
| Height (ROPS up) | 67″ | 67″ |
| Weight | 1,364-1,392 lb | 1,399-1,427 lb |
| General | |
|---|---|
| Total Fuel Capacity | 13 gallons |
| Drive Tires | 24″ x 12″-12″ |
| Caster Tires | 13″ x 6.5″-6″ |
| Seat | 4-point iso-mounted mid-back mounted on operator-suspension platform |
| Drive System | |
| Drive System Type | Hydro-Gear ZT5400 Transaxle. Two-Speed |
| Pumps | Internal Pump: 16 cc |
| Motors | Internal Motor: 21 cc |
| Forward Ground Speed | 16 mph (high-speed) 12 mph (low-speed) |
| Reverse Ground Speed | 8 mph (high-speed) 5 mph (low-speed) |
| Parking Brake | Foot-operated pedal |
| Deck | |
| Cutting Widths | 61″ and 72″ |
| Type | Velocity Plus™ |
| Cutting Height | 1.25″ to 5″ in .25″ increments |
| Deck Lift | Adjustable foot-operated pedal |
| Construction | Tri-plate cutter deck constructed of 3 steel plates totaling nearly 1/2″ of steel. Reinforcement plates at cutter deck spindles. |
| Spindles | Cast-iron housing with tapered roller bearings. |
| Blade Engagement | Adjustable air-gap for extended life. |
