Specs
| Model | Deck Width | Engine | Horsepower | MSRP |
|---|---|---|---|---|
| SZL-36H-18FR | 36″ | Kawasaki® FR Series | 18 | $5,999 |
| SZL-36H-20KT | 36″ | Kohler® 7000 Series | 20 | $5,599 |
| SZL-42H-21FR | 42″ | Kawasaki® FR Series | 21 | $6,299 |
| SZL-42H-22KT | 42″ | Kohler® 7000 Series | 22 | $6,099 |
SZL-48H-21FR  | 48″ | Kawasaki® FR Series | 21 | $6,349 |
| SZL-48H-22KT | 48″ | Kohler® 7000 Series | 22 | $6,099 |
| SZL-48H-24SR | 48″ | Scag SR Series | 24 | $5,999 |
| SZL-52H-23FR | 52″ | Kawasaki® FR Series | 23 | $6,749 |
| SZL-52H-24SR | 52″ | Scag SR Series | 24 | $6,199 |
| SZL-52H-24KT | 52″ | Kohler® 7000 Series | 24 | $6,499 |
| SZL-52H-24PX | 52″ | Briggs & Stratton® PXi Series™ | 24 | $7,399 |
| SZL-61H-24FR | 61″ | Kawasaki® FR Series | 24 | $7,249 |
| SZL-61H-26KT | 61″ | Kohler® 7000 Series | 26 | $6,899 |
| SZL-61H-27SR | 61″ | Scag SR Series | 27 | $6,999 |
| Specifications and prices subject to change without notice. Actual ground speeds may vary. Accessories subject to availability. Because we strive to continually improve our products, Scag reserves the right to make changes at any time without notice or obligation. Contact your local Scag dealer for specific availability information. | ||||
| Product Dimensions | 36″ Liberty Z | 42″ Liberty Z | 48″ Liberty Z | 52″ Liberty Z | 61″ Liberty Z |
|---|---|---|---|---|---|
| Length | 68.5″ | 68.5″ | 67.5″ | 67.5″ | 73.5″ |
| Width (chute down) | 48.5″ | 54.5″ | 60.5″ | 64.5″ | 73.5″ |
| Width (chute in transport position) | 37″ | 43″ | 49″ | 53″ | 62″ |
| Height | 40″ | 41″ | 41″ | 41″ | 41″ |
| Weight | 555 lb | 595 lb | 612 lb | 646 lb | 695 lb |
| General | |
|---|---|
| Total Fuel Capacity | 3.5 gallons (36″ and 42″) 5.5 gallons (48″, 52″ and 61″) |
| Drive Tires | 20″ x 8″-10″ (36″) 20″ x 10″-8″ (42″, 48″ and 52″) 20″ x 10″-10″ (61″) |
| Caster Tires | 11″ x 4″-5″ (36″ and 42″) 11″ x 6″-5″ (48″, 52″ and 61″) |
| Seat | Padded with arm rests, adjustment forward and back (tools required) (no armrests on 36″ and 42″ models) |
| Drive System | |
| Drive System Type | 36″ and 42″ models: Hydro-Gear ZT-2800 Transaxle 48″, 52″ and 61″ models: Tuff Torq TZ450 Transaxle |
| Pumps | Internal Pump: 10 cc |
| Motors | Internal Motor: 10cc (Tuff Torq), 16 cc (Hydro-Gear) |
| Forward Ground Speed | 7 mph |
| Reverse Ground Speed | 5 mph |
| Parking Brake | Hand lever |
| Deck | |
| Cutting Widths | 36″, 42″, 48″, 52″ and 61″ |
| Cutting Height | 1.5″ to 4.5″ in .25″ increments |
| Spindles | Aluminum housing with sealed ball bearings. |
| Construction | Dual-plate cutter deck constructed of 2 steel plates. Reinforcement plate at cutter deck spindles. |
| Deck Lift | Foot-operated pedal |
| Type | Heavy-Duty Hero Cutter Deck |
| Blade Engagement | Ogura GT1 (74 ft lb) – (36″, 42″, 48″ and 52″) Ogura GT2 (108 ft lb) – (61″) Adjustable air-gap for extended life. |
